Garia

Houghton Garia 405 M-32

Garia 405 M-32 is a neat cutting oil. It is commonly used for machining higher alloyed steels, aluminum and magnesium alloys.

Properties

Garia 405 M-32 is a chlorine free product. It is free of heavy metals and has a low aromatic content. It contains a well balanced combination of polar, extreme pressure and antiwear additives which give the oil high load carrying properties.

Due to its active sulphur content, the oil may discolor yellow metals.

Applications

Garia 405 M-32 is recommended for general machining operations such as turning, drilling and gear hobbing on steel of low to medium tensile strength, aluminum and magnesium alloys. It is also suitable for grinding where higher viscosity is required, e.g. thread grinding.

Houghton Garia 601 M-22

It is based on hydro treated mineral oils with a low aromatic content.It's formulated to a combination of polar, extreme pressure and anti-wear additives.

Properties

Its composition gives the oil high load carrying properties. Its high additive content and controlled extreme pressure properties allow high rates of metal removal, which results in reduced machining costs.

The oil provides good tool life and excellent surface finish of the machined work pieces. Efficient anti mist additives reduce mist in the air.

Due to its active sulphur content, the oil may discolor yellow metals.

Application

Garia 601 M-22 is recommended for machining high alloyed steels, stainless, heat resistant or austenitic steels and aluminum or magnesium alloys. The oil gives excellent results with many difficult operations such as broaching, deep-hole drilling, tapping, shaping or shaving of gears.

Houghton Garia 603 S-15

Neat Cutting Oil for Broaching and Severe Machining.

GARIA 603 S-15 is based on hydro treated mineral oil with low aromatic content. A combination of polar, extreme pressure and anti-wear additives provide the oil with high load carrying properties. The oil provides good surface finish of the machined work pieces.

GARIA 603 S-15 contains active sulphur and may discolour yellow metals.

The oil is zinc and chlorine free.

Applications:

GARIA 603 S-15 is a high performance product for severe operations as well as for difficult to machine materials.

GARIA 603 S-15 is designed for deep drilling with BT A. Ejector and gun drills. The oil has proven performance for severe broaching e.g. for internal broching of planetary gear rings.

Approved by Klingelnberg for Titanium grinding.

Houghton Garia 404 M-10

Properties

Garia 404 M-10 is a neat cutting oil for machining high alloyed steels, aluminum and magnesium alloys. Garia 404 M-10 is chlorine free, free of heavy metals and it has a low aromatic content. It contains a well balanced combination of polar, extreme pressure and anti-wear additives which gives the oil high load carrying properties. Due to its active sulphur content, the oil may discolor yellow metals.

Applications

Garia 404 M-10 is recommended for:

Grinding

Deep-hole drilling

Taping or broaching of low to medium alloyed steels

Gear hobbing

Machining on automatic lathes

Garia 404 M-10 is used neat as supplied.

Houghton Garia 405 M-22

Properties

GARIA 405 M-22 is based on hydro treated mineral oil with low aromatic content. A combination of polar. extreme pressure and anti-wear additives provide the oil with high load carrying properties. The oil provides good surface finish of the machined work pieces.

GARIA 405 M-22 contains active sulphur and may discolour yellow metals.

The oil is zinc and chlorine free.

Applications

GARIA 405 M-22 is the universal oil for the gear shop. It shows excellent performance for the gear grinding as well as for gear hobbing and shaping operations.

GARIA 405 M-22 is used also for the machining of steel and cast iron on automatic turning lathes.

Approvals

Hofler and Klingelnberg.

Houghton Garia 602.02 M-15

Properties

Houghton’s Garia™ series line of neat cutting oils contain active chemistry for medium to severe cutting of aluminum, cast iron, steel and stainless steel. Additives ensure long sump life and resistance to dilution with tramp oils.

The oils show excellent results by working with many difficult operations like broaching, deep-hole drilling, tapping, shaping or shaving of gears.

Using Houghton 602.02 Garia M-15 specifically in deep drilling operations allows higher cutting speeds and greater lubrication providing  very high efficiency combined with minimum wear of cutting heads and drill guides.

Chlorine Free
Low aromatics
Low oil mist and evaporation
Good wetting properties
Free of heavy metals

Houghton Garia 602.02 M-15 is a cutting oil that can be used for machining of a wide variety of materials, such as cast iron, copper alloys, aluminum alloys, steel alloys, stainless steel, acid-and heat-resistant steels.

Houghton 602.02 Garia M-15 was designed for difficult machining operations such as deep drilling, drilling, reaming, threading, grinding, broaching and gear cutting on the above mentioned materials. Using Houghton 602.02 Garia M-15 specifically in deep drilling operations allows higher cutting speeds and greater lubricity thereby providing  high efficiency combined with minimum wear of cutting heads and drill guides.

Houghton Garia 601 M-12

Properties

GARIA 601 M-12 is based on hydro treated mineral oil with low aromatic content. A combination of polar, extreme pressure and anti-wear additives provide the oil with high load carrying properties. The oil provides good surface finish of the machined work pieces

Garia 601 M-12 and M-22 are neat cutting oils for machining of high alloy steels (stainless,heat resistant, austenitic, etc.) and aluminium ormagnesium alloys.

The oils show excellent results in working with many difficult operations like broaching, deep-hole drilling, tapping, shaping,and shaving of gears.

• Garia 601 M-12 and M-22 products are also very good grinding oils.
• Garia 601 M-12 and M-22 contain active sulphur - there is a risk of staining of yellow metals.
• Garia 601 M-12 and M22 are free of chlorine and heavy metals.

Approved by Kay's Engineering (Eldorado machines) for gun drilling.
