Klüber

Klüber Klübersynth 80 KV

Synthetic high-performance gear oils for weaving machines

Application Klüber Klübersynth 80 KV

Klübersynth 50 KV, 80 KV and 100 KV are exclusively recommended by the Italian textile machine OEM ITEMA for the lubrication of gears, bearings and other sliding friction points in Leonardo-type weaving machines. For Leonardo-type weaving machines with oil coolers, ITEMA recommends Klübersynth 50 KV, and for the R 9500-type machines Klübersynth 80 KV.

Klüber Zeliot SLH 50

Pressure testing fluid for pumps and heat exchangers

Application Klüber Zeliot SLH 50

ZELIOT SLH 50 is used to test the tightness of pumps, heat exchangers and other pressure vessels in heating and sanitary installations. It also protects metal surfaces reliably against corrosion.

Klüber Klübersynth EG 4-460

Synthetic high-performance gear oil

Application Klüber Klübersynth EG 4-460

Klübersynth EG 4 was especially developed for the lubrication of heavily loaded spur, bevel and planetary gears. It can also be used for the lubrication of worm gears. Klüberoil EG 4 can also be selected for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps.

Klüber KlübersynthEG 4-680

Synthetic high-performance gear oil

Application Klüber Klübersynth EG 4-680

Klübersynth EG 4 was especially developed for the lubrication of heavily loaded spur, bevel and planetary gears. It can also be used for the lubrication of worm gears. Klüberoil EG 4 can also be selected for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps.

Klüber Klübersynth EG 4-320

Synthetic high-performance gear oil

Application Klüber Klübersynth EG 4-320

Klübersynth EG 6 was especially developed for the lubrication of heavily loaded spur, bevel and planetary gears. It can also be used for the lubrication of worm gears. Klüberoil EG 6 can also be selected for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps.

Klüber Summit LCG 68

Synthetic compressor oils for acidic and reactive gases such as landfill and biogases.

Application Klüber Summit LCG 68

The Klüber Summit LCG 68 was developed for application in screw-type compressors working with natural gases or the reactive and corrosive gases encountered in biogas plants, refineries, EOR processes or the chemical industry. Klüber Summit LCG 68 compressor oils do not contain sulphur or any other elements that might react with chlorine-containing components or acidic gases. They can also be used with gases containing chlorine where mineral oils, esters or polyglycols are not suitable for application. Klüber Summit LCG 68 compressor oils protect surfaces against the corrosive effects of acidic gases such as hydrogen sulphide or carbon dioxide. To select the right viscosity, the composition of the gas flow and all other operating conditions have to be known in detail

Klüber Klüberalfa DH 3-150

High-temperature lubricating oils for sintered metal plain bearings and plastic components

Application Klüberalfa DH 3-150

Sintered metal components Klüberalfa DH 3 oils are used for the impregnation of sintered metal plain bearings subject to high temperatures where longterm lubrication is required. Due to their high thermal and chemical stability, additional lubrication with, for example, MIKROZELLA is normally not necessary. Plastic components Klüberalfa DH 3 oils are suitable for the lubrication of both plastic components and metal-plastic sliding contact surfaces. These clear, colourless and odourless oils do not form unwanted resins. Klüberalfa DH 3 oils are generally regarded as neutral towards elastomers and plastics (possible exception: perfluorinated rubber), so no negative effect on the material is to be expected. Nevertheless compatibility with the materials should be tested, especially prior to series application.

Klüber Syntheso HT 1000

Synthetic long-term and high-temperature oils

Application Klüber Syntheso HT 1000

SYNTHESO HT oil are used for the lubrication of spur and bevel gears and rolling bearings such as spherical roller bearings in bowl mill crushers, plain bearings and gear couplings subject to high temperatures and high surface pressure. Substantially less friction and powerful protection against wear are major benefits of these products.

Klüber Klübersynth CTH 2-260

High-temperature oil for oil-lubricated stenter chains in the textile industry

Application Klüber Klübersynth CTH 2-260

With Klübersynth CTH 2-260, the range of Klüber Lubrication high-temperature chain oils has been consistently upgraded. The product can replace other Klüber Lubrication chain oils for high operating temperatures. It can be used for all types of oil-lubricated stenter chains, e.g. roller chains; chains or clips with ball bearings - combined lubrication of ball bearings, chain links and sliding rails; sliding chains in single-layer stenters, multi-layer stenters, festoon dryers, festoon steamers, coating installations - lubrication of sliding rails, chain links and chain pins

Klüber Summit Varnasolv

Concentrated, synthetic conditioner for compressors, hydraulic systems, gears and other oil circulation systems

Application Klüber Summit Varnasolv

Klüber Summit Varnasolv has been especially designed for cleaning screw-type compressors, hydraulic systems, gears and other oil circulating systems like calenders. The conditioner can be used for oils based on mineral oil, synthetic hydrocarbon, ester oil and polyglycol. Using mineral oils in oil-injected screw-type and sliding vane compressors may lead to varnish and carbon buildup in the entire oil circuit or form sticky residues on valves and hot surfaces in hydraulic systems. This often results in increased energy consumption, sticky valves, clogged oil lines and filters and increased downtime due to maintenance. Klüber Summit Varnasolv is a concentrated conditioner fluid which dissolves varnish and carbon buildups during operation and keeps them suspended in the compressor oil. Therefore, it is no longer necessary to dismantle the system for cleaning. The oil containing the residues is completely drained before refilling the unit with fresh oil.

Klüber Klübersynth GEM 4-46 N

Synthetic high-performance gear and multipurpose oil with KlüberComp Lube Technology

Application Klüber Klübersynth GEM 4-46 N

Klübersynth GEM 4 N was specially developed for the lubrication of spur, bevel, hypoid and planetary gears that are subject to high loads. Such gears are frequently used in the wind, steel, mining and sugar industries. It is also used for the lubrication of standard worm gears as defined in DIN 3996. Klübersynth GEM 4 N can also be used for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps, especially in applications where the equipment is exposed to elevated temperatures or pronounced temperature fluctuations.

Klüber Klübersynth EG 4-1000

Synthetic high-performance gear oil

Application Klüber Klübersynth EG 4-1000

Klübersynth EG 4 was especially developed for the lubrication of heavily loaded spur, bevel and planetary gears. It can also be used for the lubrication of worm gears. Klüberoil EG 4 can also be selected for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps.

Klüber Summit DSL 32

Fully synthetic air compressor oils for oil change intervals up to 8,000 operating hours

Application Klüber Summit DSL 32

The Klüber Summit DSL 32 … 68 oils have been especially designed for oil change intervals up to 8,000 operating hours* in oil-injected screw-type compressors. Klüber Summit DSL 32 and 46 can also be used for the lubrication of centrifugal compressors, whereas Klüber Summit DSL 68 ... 125 is particularly suitable for the lubrication reciprocating piston compressors. Klüber Summit DSL oils are used for compressors that were previously run with conventional mineral oils. These oils are neutral towards most elastomer seals used in air compressors, therefore leakage is not to be expected. Klüber Summit DSL oils are mainly used in reciprocating piston compressors which do not achieve the desired maintenance intervals when using mineral oils or which show severe residue formation (carbon buildups) on valves and in the compression chamber. Klüber Summit DSL 32, 46, and 68 are biodegradable and can therefore be used in eco-sensitive applications. Klüber Summit DSL oils offer good oxidation stability due to the synthetic base oil, thus minimizing oxidation residues in the compressors and extending oil change intervals and the service life of oil filters and separators (screw-type compressors) and valves (reciprocating piston compressors).

Klüber Klüberfood NH1 M 4-150

Fully synthetic high-performance oils for high-speed can closing machines

Application Klüber Klüberfood NH1 M 4-150

Lubrication of can seaming machines with either recirculating or total loss systems. Especially for those systems that have contamination of water or juice mixtures that need to be filtered. Circulating oil systems for bearings, chains and open gears on equipment in the food and beverage industry.

Klüber Summit R 300

Synthetic compressor oils, particularly for highly loaded ammonia and CO2 refrigeration plants

Application Klüber Summit R 300

Klüber Summit R series lubricants have been designed especially for highly loaded screw-type and reciprocating piston compressors which are operated with ammonia (R717) or CO2 (R744). These lubricants can also be used with natural hydrocarbon refrigerants like propane (R290), propylene (R1270) or butane (R600). Especially with these refrigerants, the solubility of the gas in the oil under operating conditions and the resulting drop in viscosity has to be taken into account. Klüber Lubrication would be pleased to assist you in selecting the most appropriate oil. Due to the synthetic base oil contained in the Klüber Summit R series lubricants, oil carryover into the refrigeration cycle is much lower than with conventional mineral oils, which helps to reduce oil consumption. The viscosity of the oils remains constant for a long time, due to the fact that only a few highly volatile fractions are contained in the oil. Oil changes due to the increase in viscosity can be extended considerably. The base oil offers high chemical stability, particularly to ammonia, the typical blackening of conventional mineral oils or deposits in the refrigeration cycle are prevented. Our experience gained in practice has shown that Klüber Summit 200 can be used for evaporating temperatures as low as ≥-50°C depending on the operating conditions.

Klüber Summit RPS 52

Synthetic compressor oil based on polyglycol for ammonia refrigerating plants using dry evaporation

Application Klüber Summit RPS 52

Klüber Summit RPS 52 has been designed especially for the lubrication of screw-type compressors in refrigerating plants using ammonia (R 717) and dry evaporation. Unlike mineral oils and polyalphaolefins, Klüber Summit RPS 52 is miscible with ammonia, thus the oil entrained in the refrigeration cycle is recycled to the compressor together with the refrigerant. Therefore, it is no longer necessary to have oil catches in the refrigeration cycle, like in the case of nonmiscible oils. Especially in the evaporator of the refrigeration cycle such miscibility helps to reliably recycle the oil to the compressor at low evaporator temperatures. Owing to the synthetic base oil of Summit RPS 52 oil carryover into the refrigeration cycle is much lower than with conventional mineral oils. Therefore, oil-related problems in the refrigeration cycle are prevented right from the beginning. The base oil of Klüber Summit RPS 52 stands out for its stability to ammonia – the typical blackening of conventional mineral oils or deposits in the refrigeration cycle are prevented and oil change intervals can be extended considerably. Our experience gained in practice has shown that Klüber Summit RPS 52 can be used for evaporating temperatures as low as -40°C depending on the operating conditions. Klüber Summit RPS 52 protects against wax-like deposits, thus increasing the efficiency of the refrigeration plant.

Klüber Summit SH 100

Synthetic air compressor oils for oil change intervals up to 10,000 operating hours

Application Klüber Summit SH 100

Klüber Summit SH oils have been designed especially for the lubrication of highly loaded, oil-injected screw-type compressors with oil change intervals up to 10,000 operating hours. Klüber Summit SH oils can also be used for compressors that were previously run with mineral oils. They are neutral towards most elastomer seals used in air compressors, therefore leakage is not to be expected. Klüber Summit SH 32 is especially suitable for centrifugal compressors and Klüber Summit SH 100 for reciprocating piston compressors. Klüber Summit SH oils offer good oxidation stability due to the synthetic base oil, thus minimizing oxidation residues in the compressors and extending oil change intervals and the service life of oil filters and separators. Special inhibitors contained in the oils keep the inside of compressors clean. Owing to the evaporation stability of the base oil, the oil vapour content in the compressed air can be considerably reduced compared to conventional mineral oils. This contributes to a reduction of oil consumption and clean compressed air; gumming of pneumatic valves in the compressed air circuit can be prevented as well due to the low oil content of the Klüber Summit SH oils.

Klüber Quietsch-Ex

Universal Fluid

Application Klüber Quietsch-Ex

For industry, workshops, automobiles, motorcycles. Used as lubricating oil, for bearings, slideways, chains, locks and hinges. A thin film is sufficient to reduce friction and wear. Used as penetrating oil, QUIETSCH EX penetrates well into cracks and even reaches friction points of difficult access. Used as rust remover, QUIETSCH EX loosens rust on screws, hinges and bolts such that they can be undone without damage. The fluid spreads quickly and penetrates into the surfaces. Light rust will be loosened rapidly but heavy rust will require a wait. Used as anticorrosion agent, QUIETSCH EX protects machinery, equipment, tools, vehicles etc. that are not used for a longer period of time (e.g. in winter time) reliably against corrosion. Used as freezing protection, QUIETSCH EX prevents freezing of locks, cables, car doors, gates etc. at temperatures as low as –30°C (if applied on parts beforehand). Used as cleaning oil, for heavily contaminated machine elements, QUIETSCH EX penetrates into machine parts and removes dirt. Used as cutting oil, QUIETSCH EX ensures clean cutting and precision drilling in synthetic materials and metal. A small quantity of this universal fluid on the saw or drill is sufficient to make the tool cut easier through the material. This facilitates work and extends the tool's service life.

Klüber Syntheso HT 1500

Synthetic long-term and high-temperature oils

Application Klüber Syntheso HT 1500

SYNTHESO HT oil are used for the lubrication of spur and bevel gears and rolling bearings such as spherical roller bearings in bowl mill crushers, plain bearings and gear couplings subject to high temperatures and high surface pressure. Substantially less friction and powerful protection against wear are major benefits of these products.

Klüber Syntheso D 1000

Synthetic high-temperature lubricating oils

Application Klüber Syntheso D 1000

SYNTHESO D oils are used for the lubrication of friction points subject to high temperatures. They are also used as pressure fluids in high-temperature applications, and as heat carrier fluids. Owing to the base oil’s high pressure absorption capacity and good wear protection, SYNTHESO D oils are particularly suitable for hydraulic or heat transfer applications where lubricity has to be ensured at high temperatures.
